Product

Ortofon LH-2000 Headshell

In stock
Ortofon SH-4 headshells are high-quality, solid headshells for variety of applications The SH-4 headshell has an ergonomic design with a long finger that is easy to pick-up. The big finger The LH-2000 is a basic high quality headshell designed specifically... Read More
Phono Cartridges & Accs. -

Ortofon SH-4 headshells are high-quality, solid headshells for variety of applications

The SH-4 headshell has an ergonomic design with a long finger that is easy to pick-up. The big finger The LH-2000 is a basic high quality headshell designed specifically for HiFi applications. Providing a clean, minimalist aesthetic, the LH-2000 is great for a wide variety of cartridges, e.g. the 2M Series and the MC High Output series.
Knowing the fundamental headshell dimensions will in a lot of cases make it easier to mount and align cartridge and tonearm correctly.

The LH-2000 comes with leadwires for easy and convenient connection
All Ortofon cartridges have a colour coding of the terminals, indicating red and green for right channel respectively hot and ground terminal. White and blue for left channel respectively hot and ground terminal. Green terminal will always be used for grounding the cartridge housings or motor-system, whenever connected inside the cartridge.

We recommend to connect lead wires to the cartridge and headshell before mounting the cartridge on the headshell.

Please remember correct orientation of the leads. Ortofon cartridges' terminal PINs diameter is 1.2 mm, whilst Ortofon headshells' PINs diameter is only 1.0 mm.

Features and Technical Data:

  • Universal mount
  • Solid aluminum build
  • Weight - 15.5 grams
  • Mounting distance - min 35.3 mm, max 43.4 mmgrip and shorter construction makes movement and placement of the headshell easy and visible.
    Read Less
